Auto Trans Shifter Cross Shaft Linkage Bushing Spring Kit For Chevy 10040797

Description:

High quality & Fast Shipping & Shipped From USA

Warranty: 5 Years

Condition: 100% Brand New & Fast Free Shipping

Material: Metal, Plastic

Manufacturer Part Number:For M463GB, 10236109, 10040797, 492346

Interchange Part Number:1377083, JO121, 15538092, 1380549, 12338114, 9423919, 3824159

Type:     Spring, Bushing

Fitment Type:Direct Replacement

Year:For 1967-1988



Feature:

Offering a new Automatic Transmission Shift Linkage Bushing and Spring Kit.

Bushing is made of hard white nylon. Replaces GM #1377083.

Spring measures 2 3/4" x 5/8". Replaces GM #10236109, 15538092, 1380549.

Measurements of bushing:

0.240" (6.25mm) Tall

0.4465" (11.5mm) Inside Diameter

1.0470" (26.65mm) Outside Diameter

Washer 3/4" OD x 7/16" ID x .060 thick

(Please allow 1-3 mm measuring deviation due to manual measurement.)

Hair Pin clip GM # 12338114 Old # 10040797

These Parts are located under the driver's side firewall at a bracket assembly bolted to the frame.

The range selector equalizer shaft end contains the spring with a washer mounted up against the white

plastic bushing that sits in the bracket.

This fits all A & G Body GM Cars along with most RWD GM

cars and trucks with automatic transmissions from 1967 - 1996.

Note:

Please Take a Look at Your Old One Before Ordering.

Please Be Very Careful to Check Our Photos, Make Sure The Photos Showed Is The Same as You Wanted.



Fits Vehicles:



This spring kit Fits (but not limited to) the following GM A & G Body models:

Fit For Buick: Regal / Grand National 1973 - 1987

Fit For Buick: Century 1973 - 1980

Fit For Buick: Skylark / GS 1967 - 1972

Fit For Chevrolet Malibu 1967 - 1983

Fit For Chevrolet Monte Carlo / SS 1970 - 1988

Fit For Chevrolet El Camino 1967 - 1987

Fit For GMC Caballero / Sprint 1971 - 1987

Fit For Oldsmobile Cutlass / 442 1967 - 1988

Fit For Pontiac Grand Prix 1969 - 1987

Fit For Pontiac Grand Am 1973 - 1980

Fit For Pontiac LeMans / GTO 1967 - 1981

Fit For ADDITIONAL APPLICATIONS:

Fit For Buick Electra 1982-1986

Fit For Buick Estate Wagon 1982, 1983, 1987, 1991

Fit For Buick Lesabre 1982-1990

Fit For Buick Regal 1982-1987

Fit For Buick Roadmaster 1991-1996

Fit For Cadillac Deville 1982-1984

Fit For Cadillac Fleetwood 1982-1996

Fit For Cadillac SPECIAL 1982-1984

Fit For Chevrolet BLAZER 1982-1994

Fit For Chevrolet C10 1985-1986

Fit For Chevrolet C1500 1990-1994

Fit For Chevrolet C20 1985-1986

Fit For Chevrolet C2500 1990-1994

Fit For Chevrolet C30 1985-1986

Fit For Chevrolet C3500 1990-1994

Fit For Chevrolet Caprice 1982-1996

Fit For Chevrolet El Camino 1982-1988

Fit For Chevrolet HEARSE/LIMO 1991-1994

Fit For Chevrolet Impala 1982, 1983, 1984, 1985, 1994, 1995, 1996

Fit For Chevrolet K10 1985-1986

Fit For Chevrolet K1500 1990-1994

Fit For Chevrolet K20 1985-1986

Fit For Chevrolet K2500 1990-1994

Fit For Chevrolet K30 1985-1986

Fit For Chevrolet K3500 1990-1994

Fit For Chevrolet Malibu 1982-1983

Fit For Chevrolet Monte Carlo 1982-1988

Fit For Chevrolet P20 1985-1990

Fit For Chevrolet P30 1985-1990

Fit For Chevrolet R10 1987-1991

Fit For Chevrolet R1500 1987-1991

Fit For Chevrolet R20 1987-1991

Fit For Chevrolet R2500 1987-1991

Fit For Chevrolet R30 1987-1991

Fit For Chevrolet R3500 1987-1991

Fit For Chevrolet S10 1982-1994

Fit For Chevrolet SUBURBAN 1985-1994

Fit For Chevrolet Tahoe 1992-1994

Fit For Chevrolet V10 1987-1991

Fit For Chevrolet V20 1987-1991

Fit For Chevrolet V30 1987-1991

Fit For Chevrolet V3500 1987-1991

Fit For GMC C10 1985-1986

Fit For GMC C1500 1990-1994

Fit For GMC C20 1985-1986

Fit For GMC C2500 1990-1994

Fit For GMC C30 1985-1986

Fit For GMC C3500 1990-1994

Fit For GMC Forward Control 1985-1991

Fit For GMC JIMMY 1983-1994

Fit For GMC K10 1985-1986

Fit For GMC K1500 1990-1994

Fit For GMC K20 1985-1986

Fit For GMC K2500 1990-1994

Fit For GMC K30 1985-1986

Fit For GMC K3500 1992-1994

Fit For GMC P2500 1985-1990

Fit For GMC P3500 1985-1990

Fit For GMC Pickup 1982-1994

Fit For GMC Postal 1987-1995

Fit For GMC R1500 1987-1989

Fit For GMC R2500 1987-1989

Fit For GMC Sierra 1992-1994

Fit For GMC TYPHOON 1991-1994

Fit For GMC V1500 1987-1989

Fit For GMC V2500 1987-1989

Fit For GMC YUKON 1992-1994

Fit For Oldsmobile 98 1982-1984

Fit For Oldsmobile BRAVADA 1991-1994

Fit For Oldsmobile Custom Cruiser 1982, 1983, 1990, 1991, 1992

Fit For Oldsmobile CUSTOM CRUISER 1984-1987

Fit For Oldsmobile Cutlass 1982-1988

Fit For Oldsmobile Cutlass Cruiser 1982-1983

Fit For Oldsmobile Cutlass Supreme 1982-1987

Fit For Oldsmobile Delta 88 1982-1990

Fit For Pontiac Bonneville 1982-1986

Fit For Pontiac Grand Prix 1982-1987

Fit For Pontiac Parisienne 1982-1986

Fit For Pontiac Safari 1987-1989



 Package Included:

 1 Set Auto Trans Shifter Cross Shaft Linkage Bushing Spring Kit 锛?/span>show as pictures锛?/span>

(instruction manual is not included.)
